Sauna heater wiring diagram. Sauna heater wiring and hookup also refer to figure 1 refer to chart above for proper wire size and amperage. All wiring should be done by a licensed electrician. Assortment of sauna heater wiring diagram. American electrical advice forum. How to take a sauna when taking a sauna allow time to relax completely. All wiring must comply with local and state ordinances.
Supply cable must have 5 wires including insulated neutral plus separate ground. On this video we show basic electrical wiring for heater light sensor and control panel. This heater not 110 volt. Install the heater fence below the level of the sauna stones. Hot or load neutral and a ground wire runs from the control panel directly to the heater through the ceiling or through the wall. To restart the heater let the heater cool and turn the timer down to zero off then push the reset button on the bottom of the heater see diagram 1.
Wire the heater according to the diagram. Mount the heater with screws provided so that the bottom of the heater is 7 from the lowest point of the sauna room floor. See page 3 for required clearances. Refer to electrical diagram of manual. If the high limit continually shuts off the heater contact a service representative. A wiring diagram is a simplified conventional photographic depiction of an electric circuit.
Most sauna heaters at least any with real power require an 8 3 wire and 12 3 wire to power the control panel light switch and any other lights and wall outlets. Use copper wire from load center to wall mounted contactor. Sawo sauna rooms are easy to assemble. Using your sauna every week will cost you 60 to 70 cents per session or 60 to 180 per week. The 8 3 wire meaning 8 gauge with 3 wires. Sauna heater wiring sizes sizing the sauna heater sizing the sauna heater to match the sauna is important to keep the warm up time to 20 to 25 minutes the average home sauna used 2 or 3 times per week will cost about 60 cents per session to operate.
Replace bottom cover once wiring is com plete. Its 220 240 volt heater and power line is 220 volt. Its mean there is two hot wire. All wiring into the sauna room must be rated for at least 194 farenhiet 90 degrees celsius standard sauna ceiling height is 7 feet.
