The red power wire on the electric a frame tongue jack lc285318 is the power wire and it will attach to the positive battery terminal on your trailer batteryfirst remove the fuse in the in line fuse holder on the red wire. I recommend checking your ground connections normally in the mount of the jack to the frame for solid metal to metal contact without corrosion.
Quick Products Jq 3500b Electric Tongue Jack Black
Lippert power tongue jack wiring diagram. Mount the jack to the trailer and tighten it down. Fuse is located underneath the lid fig. The lippert electric stabilizer jack is intended for the purpose of 38 dia. See page 5 of the power tongue jack owners manual. I took the jack apart and straightened out the inner tube and all is well however the two bolts on the head on the side of the jack appear to be very loose after trying to put them back in i dont have them stripped or anything but its almost like they are just falling in place instead of screwing in place. The quick drop tongue jack is the first rv jack of its kind allowing rvers to extend and retract the jack using a power drill and ¾ socket head.
It must be replaced with a 30a ato type fuse. Welding electric stabilizer jack to unit voids all warranty claims. Lippert power jack 1817941. I attached a picture that i got from lippert that shows the wiring diagram for their stabilizer jacks like the. 5b of the jack and will need to be replaced if it blows. It is important that the electrical components have good wire to chassis contact.
A negative ground system utilizes the chassis frame as a ground and an independent ground wire back to battery is necessary see page 9 for wiring diagram. In the main frame rails in the a positions in the above diagram. Normally an intermittent working motorized jack like the lippert components powered tongue jack lc285318 is due to a faulty ground or a short circuit in the power wire. Just flip over the manual crank handle to expose a ¾ hex nut insert the socket head and using your power drill the quick drop tongue jack extends and retracts in seconds without the exhaustive. The lippert electric rear stabilizer jack is designed to operate as a negative ground system. What type of fuse does the power tongue jack contain and where is it located.
See page 6 of the power tongue jack owners manual. 04022014 page 6 power tongue jack owners manual full power tongue jack clutch the power tongue jack is provided with a motor clutch and a 30a fuse. Here you can find a document containing all of the owners for all our product lines.
