Wet switch flood detector a solid state control designed to help prevent flooding damage to carpets walls furniture ceilings etc. 2 amp contact rating.
Wet Switch Flood Detector
Wet switch flood detector wiring diagram. Ws 1 wet switch flood detector led indicators wet switch test reset buttons. Connect green wire from wet switch to common wire that was cut from transformer in step 4. Now has a built in test and reset button for easier installation. A lit led indicates the wet switch is activated and has turned the unit off. Wire can be extended if necessary. Wires may be extended as necessary but avoid excess run lengths.
Controlling selected components system components such as compressors electric valves condenser model no. Etl listed file number 3146992. It turns the system off when moisture due to condensate or drain leaks is detected. Connect red wire from wet switch to 24vac of transformer. Restore power to the system. Connects to 24 vac.
Diversitech ws 1 wet switch flood detector the wet switch flood detector is a solid state control designed to help prevent flooding damage to carpets walls furniture ceilings etc. Connect black wire from wet switch to same wire on transformer where common was cut. Connect wiring as shown in the diagrams on page 2. It now has a built in test and reset button. Image 2 depicts hydrophilic pad image 3 depicts integral feet image 4 depicts stainless steel sensors the wet switch flood detector is a solid state control designed to help prevent flooding damage to carpets walls furniture ceilings etc. Route the cable from the wet switch to cooling control voltage transformer as shown in the wiring diagram.
One or two drops will cause wet switch to turn off a unit alerting a. Diversitech ws 1 wet switch flood detector note. Turns system off when detecting moisture due to condensate or drain leaks. Simple 5 wire installation. Reset simply by drying the absorbent pad with a paper towel and pressing the reset switch. It now has a built in test and reset button for easier installation.
More than one unit may be connected to a system. Cut common wire of transformer.
