Standard wiring diagrams 3 loads load circuit fuse breaker auxiliary battery start battery fuse sbi 3 3 5 4 6 7 1 sbi with external led sbi with push button for start assist momentary pushbutton momentary pushbutton led resistor values. When you start your engine the redarc works by first letting your starter battery recover its charge it lets it achieve 132 volts at this point that battery has about as much charge in it as its going to get once the redarc sees this 132 volts it closes the contacts on the solenoid this links both batteries.
The Redarc Smart Start Vsr Battery Isolator And How It Works
Redarc vsr wiring diagram. Bcdc dual with jump start the new ultimate dual battery setup. Check them out today. Specification model vs12 vs24 supply range 12v 24v sensing range 90 160v 180 350v output current rating 10a 10a recommended fusecircuit breaker rating white wire 10a 10a dimensionsmm 75x30x24mm 75x30x24mm weight 70g 70g warranty 2 years 2 years factory settings 127v on 12v off 02v 256v on 24v off 04v connections. Override wire override wire. Bcdc1240 with 12v and solar inputs and jump start feature. The below diagram shows how to install a gauge using switches to simulate ignition and dash lights providing a simple way to switch the gauge onoff both withwithout the backlight active.
The trailer brake control is connected to pin5 of the trailer plug. View redarcs library of wiring guides and installation setups for our range of in vehicle battery chargers and isolators. The earth is connected to a convenient chassis earth bolt. Redarc recommend the following wiring configuration. Ultimate dual battery setup for winching. 12v 1kω or 24v 22kω sbi with push button and led no resistor required.
When wiring a gauge into a location other than a car dashboard for example in a caravan park and dash lights may not be available. The redarc smart start vsr voltage sensitive relay battery isolator. Redarc electronics have a large database of faqs tech tips wiring diagrams and how to guides. Battery power is connected directly to the battery through an auto reset circuit breaker recommend redarc cbk 30e white wire.
