Io module low ambient kit function setting of dip switch using sw101 sw102 you can use low ambient kit mode sw102 sw101 notes default status is all off. Caution if the dip sw is set io module system is operating preferentially than outdoor unit setting.
Lennox Controls And Hvac Accessories Manual L0806303
Low ambient kit wiring diagram. Wire lowambient pressure switch as follows. Connect yellow or violet lead from lowambient pressure switch to same nc terminal of isolation relay. Diagram label 48tm502162 1 caution label 48tm501658 1. Io module low ambient kit function setting and using method 3. Connect a wire from outdoor fan relay terminal number. Affix the low ambient kit wiring diagram on the control box door next to the unit wiring diagram.
Remove black fan lead from outdoor fan relay terminal number 3 and reconnect it to nc terminal of isolation relay. After change dip sw setting press reset switch to reflect the setting. The lakt01 and lakt03 kits are shipped with wiring diagram included. Using sw101 sw102 you can use low ambient kit mode set low ambient kit operation l1 on 2 3 4 l1 on 2 sw102 sw101 notes default status is all off. Low ambient operation motormasterr v control accessory 5060hz. Lakt01 3 thru 6 tons wiring diagram 0140m00108 use with ac and hp units three phase and single phase application.
1 1 025 32750 000 low ambient con trol lac includes mounting tape sen sor and cable straps 2 1 035 16751 000 kit instruction form 3 1 ab096blu7157804 wire 804blu 4 1 ab096blk7171805 wire 805blk 5 1 ab096yel7171806 wire 806yel 6 1 ab096brn7157807 wire 807brn 7 1 035 16720 000 wiring diagram 3 6 ton 8 1 035 15369 000 wiring diagram 75. For residential 3 phase condensers connect wires per 0140m00108 wiring diagram. 2 additional parts for heat pump units package content of crloamhp001a00 heat pump adapter kit item crloamhp001a00 qty relay motomaster v fan hn61kk055 1 fiop asy relay base hn79kk035 1.
