For the mtx l and lc 2 the default analog outputs are reversed so youd wire the yellow analog out 1 wire to the megasquirts o2 input wire. This diagram demonstrates how a relay is installed to power a low and high amp circuit.
Wideband O2 Installation Overview Adventure Rider
Innovate wideband gauge wiring diagram. Route the sensor cable. All that is needed for basic installation is power red and ground black. 29082018 29082018 5 comments on innovate afr gauge wiring innovate dlg 1 air fuel ratio gauge mustang install this story were going to install a dlg 1 digital airfuel. For any lc 1 purchased after june2006 that should be all you need to be concerned with when wiring it up. 211 single innovate device relay wiring instructions 22 mounting and routing the mtx l gauge fits in any standard 2 116 52mm gauge pod. Can anyone help me out.
I am aware that you take the lc 1 analog output 2 wire and connect it to the eiao input 1 or 2 or 3 or 4. One gauge three functions. The method i demonstrated makes it easy to remove your work and return the car to stock by simply un plugging the wideband controller and gauge and re installing a factory o2 sensor. For the lc 1 wire the brown analog out 2 wire to the megasquirts o2 input wire. A better course of action is to create a stand alone circuit just for the wideband sensor and gauge using a standard automotive relay. The two configurable analog output wires one yellow and one brown can be used to feed external standalone ecus 3rd party data loggers and afr display gauges.
2 1 overview the lc 1 is a stand alone wideband controller used to measure the airfuel ratio afr or lambda for an engine. Mounting of the gauge should be done in such a manner that the cables are not being forcefully pulled and strained from the gauge itself. The db gauges white wire is the signal input from the wideband controller. Connect the db gauges white wire to the lc 1s brown wire. Connect the db gauges white wire to the lc 2s yellow wire. Is there a no bullshit way to setup hptuners pro for the innovate lc 1 wideband sensor.
The new innovate motorsports scg 1 solenoid boost controller oled gauge is now available. The gauge is setup to work with an analog output configuration of 0v 735 af and 5v 2239 af. For gasoline driven engines the theoretically optimal air fuel ratio is 147 pounds of air for every pound of fuel. Single innovate device relay wiring instructions 5. I have done a search and read just about all the threads concerning the lc 1 but not one truly answers the right way to set everything up for the lc 1 to work with hptuners pro. Wiring the lc 2s wiring is very straight forward.
